Heavy Duty Castors
In relation to mass and weight, modern heavy industry often thinks in dimensions that are a feat of strength for people and machines. For example, take a passenger bridge for the harbour, construction machines for road building, etc. All these heavy weights need to be moved. You’ll be doing well if you deal with these tasks on super-stable heavy load castors from Colson. Because in materials quality and processing, they are the absolute master in their class. This you can depend upon.
BXPF 0801 7100
BXPF 0801 7100 80 mm - 200 mm, 120 kg - 300 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 32 mm |
| Hub length | 42 mm |
| Height | 105 mm |
| Offset | 38 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9.6 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 113 mm |
| Load capacity | 120 kg |
| Weight | 0.7 kg |
Wheel
- Dark grey Polypropyleene wheel with grey rubber tyre
- (Performa, Shore A 65 - 70) with one deep groove ball bearing
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race and sealring
- with a total lock brake
