JSPC 0802 7000/B
JSPC 0802 7000/B 80 mm - 200 mm, 120 kg - 250 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 32 mm |
| Hub length | 45 mm |
| Height | 105 mm |
| Offset | 40 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 120 mm |
| Load capacity | 120 kg |
| Weight | 0.86 kg |
Wheel
- Dark grey Polypropyleene wheel with grey antistatic rubber tyre
- (Performa, Shore A 65 - 70) with one stainless steel deep groove ball bearing
Technical description
- Swivel fork of deep drawn zinc-coated steel with wheel brake. Swivelhead with sealed precision
- ball bearing and a grease nippel
JSPF 0802 5000
JSPF 0802 5000 80 mm - 200 mm, 120 kg - 300 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 32 mm |
| Hub length | 45 mm |
| Height | 105 mm |
| Offset | 40 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 120 mm |
| Load capacity | 120 kg |
| Weight | 0.72 kg |
Wheel
- Dark grey Polypropyleene wheel with grey rubber tyre
- (Performa, Shore A 65 - 70) with one deep groove ball bearing
Technical description
- Swivel fork of deep drawn zinc-coated steel Swivelhead with sealed precision ball bearing and a grease nippel
JSPF 0802 5000/B
JSPF 0802 5000/B 80 mm - 200 mm, 120 kg - 300 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 32 mm |
| Hub length | 45 mm |
| Height | 105 mm |
| Offset | 40 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 120 mm |
| Load capacity | 120 kg |
| Weight | 0.87 kg |
Wheel
- Dark grey Polypropyleene wheel with grey rubber tyre
- (Performa, Shore A 65 - 70) with one deep groove ball bearing
Technical description
- Swivel fork of deep drawn zinc-coated steel with wheel brake. Swivelhead with sealed precision
- ball bearing and a grease nippel
JSPG 0802 6123
JSPG 0802 6123 80 mm - 250 mm, 50 kg - 340 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 25 mm |
| Hub length | 45 mm |
| Height | 110 mm |
| Offset | 40 mm |
| Wheel axle diameter | 12 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 120 mm |
| Load capacity | 50 kg |
| Weight | 0.9 kg |
Wheel
- Polyamide wheel with grey rubber tyre
- (Shore A 85) and two deep groove ball bearings
Technical description
- Swivel fork of deep drawn zinc-coated steel Swivelhead with sealed precision ball bearing and a grease nippel
JSPG 1602 6443/B
JSPG 1602 6443/B 160 mm - 250 mm, 175 kg - 340 kg
Technical data
| Diameter | 160 mm |
| Wheel width | 40 mm |
| Hub length | 64 mm |
| Height | 195 mm |
| Offset | 55 mm |
| Wheel axle diameter | 20 mm |
| Top plate dimensions | 135 x 112 mm |
| Top plate hole diameter | 11 mm |
| Dist. between holes | 105 x 75,80 mm |
| Brake swivel radius | 145 mm |
| Load capacity | 175 kg |
| Weight | 2.9 kg |
Wheel
- Polyamide wheel with grey rubber tyre
- (Shore A 85) and two deep groove ball bearings
Technical description
- Swivel fork of deep drawn zinc-coated steel with wheel brake. Swivelhead with sealed precision
- ball bearing and a grease nippel
JSPM 0802 6121
JSPM 0802 6121 80 mm, 50 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 25 mm |
| Hub length | 45 mm |
| Height | 110 mm |
| Offset | 40 mm |
| Wheel axle diameter | 12 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 120 mm |
| Load capacity | 50 kg |
| Weight | 0.9 kg |
Wheel
- Polyamide wheel with black rubber tyre
- (Shore A 85) and two deep groove ball bearings
Technical description
- Swivel fork of deep drawn zinc-coated steel Swivelhead with sealed precision ball bearing and a grease nippel
JSPM 0802 6121/B
JSPM 0802 6121/B 80 mm, 50 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 25 mm |
| Hub length | 45 mm |
| Height | 110 mm |
| Offset | 40 mm |
| Wheel axle diameter | 12 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 120 mm |
| Load capacity | 50 kg |
| Weight | 1.1 kg |
Wheel
- Polyamide wheel with black rubber tyre
- (Shore A 85) and two deep groove ball bearings
Technical description
- Swivel fork of deep drawn zinc-coated steel with wheel brake. Swivelhead with sealed precision
- ball bearing and a grease nippel
JSPM 1002 6151/B
JSPM 1002 6151/B 100 mm - 250 mm, 80 kg - 340 kg
Technical data
| Diameter | 100 mm |
| Wheel width | 30 mm |
| Hub length | 45 mm |
| Height | 130 mm |
| Offset | 40 mm |
| Wheel axle diameter | 15 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 120 mm |
| Load capacity | 80 kg |
| Weight | 1.3 kg |
Wheel
- Polyamide wheel with black rubber tyre
- (Shore A 85) and two deep groove ball bearings
Technical description
- Swivel fork of deep drawn zinc-coated steel with wheel brake. Swivelhead with sealed precision
- ball bearing and a grease nippel
JSPM 2002 6441
JSPM 2002 6441 200 mm - 250 mm, 270 kg - 340 kg
Technical data
| Diameter | 200 mm |
| Wheel width | 50 mm |
| Hub length | 64 mm |
| Height | 235 mm |
| Offset | 60 mm |
| Wheel axle diameter | 20 mm |
| Top plate dimensions | 135 x 112 mm |
| Top plate hole diameter | 11 mm |
| Dist. between holes | 105 x 75,80 mm |
| Brake swivel radius | 145 mm |
| Load capacity | 270 kg |
| Weight | 3.4 kg |
Wheel
- Polyamide wheel with black rubber tyre
- (Shore A 85) and two deep groove ball bearings
Technical description
- Swivel fork of deep drawn zinc-coated steel Swivelhead with sealed precision ball bearing and a grease nippel
JSPN 0802 5000
JSPN 0802 5000 80 mm - 125 mm, 175 kg - 250 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 30 mm |
| Hub length | 45 mm |
| Height | 110 mm |
| Offset | 40 mm |
| Wheel axle diameter | 8 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 120 mm |
| Load capacity | 175 kg |
| Weight | 0.6 kg |
Wheel
- Polyamide wheel with one sealed deep groove ball bearing
Technical description
- Swivel fork of deep drawn zinc-coated steel Swivelhead with sealed precision ball bearing and a grease nippel
